Balluff
Balluff BES030F 电感式接近传感器
方形，高度 26 毫米
Balluff BES030F 电感式接近传感器 — datasheet、规格参数、订货号查询与原装正品采购
获取报价 / 询盘
技术规格
| Dimension | 26 x 26 x 43 mm |
| Style Housing | 26x26 |
| Installation | for flush mounting |
| Range | 10 mm |
| Switching output | polarized Normally open (NO) |
| Switching frequency | 250 Hz |
| Housing material | PA |
| Material sensing surface | PA |
| Connection | Cable with connector, M12x1-Male, 4-pin, 0.80 m, PUR |
| Operating voltage Ub | 10...36 VDC |
| Ambient temperature | -25...70 °C |
| IP rating | IP67 |
| Approval/Conformity | CE WEEE UKCA |
下载资料
- BES Z03K-GSS10B-EP00,8-GS04-006 (161 KB)
