Balluff

Balluff BOS027M Retroreflective sensors

Cubic retro-reflective photoelectric sensors with different types of light

Balluff BOS027M Retroreflective sensors — datasheet, specifications, part number lookup & authentic sourcing

Get a Quote / Inquire

Specifications

Special characteristics	Washdown
Series	21M
Dimension	15.4 x 51.1 x 42.7 mm
Interface	IO-Link: 1.1PNP: Normally open (NO)PNP: Normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Retroreflective sensor
Beam characteristic	Divergent
Light type	LED Red light
Range	0...10 m
Connection	Connector, M12x1-Male, 4-pin
Housing material	Zinc, Die casting, Powder coatedDie-cast zinc
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	CE UKCA cULus WEEE E c o l a b
