Balluff
Balluff BOS01Z8 Diffuse sensors
Cubic diffuse sensors with different types of light
Balluff BOS01Z8 Diffuse sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Series | 21M |
| Dimension | 15 x 51 x 42.5 mm |
| Interface | PNP: Normally open (NO)PNP: Normally closed (NC) |
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Diffuse sensor, Triangulation |
| Special optical feature | Background suppression |
| Beam characteristic | Focus, typical at 200 mm |
| Light type | LED Red light |
| Light spot size | 6 x 6 mm at 200 mm |
| Range | 1...400 mm |
| Connection | Connector, M12x1-Male, 4-pin |
| Housing material | Zinc, Die casting, Powder coatedAluminum |
| Material sensing surface | Glass |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | CE UKCA cULus WEEE |
Downloads
- BOS 21M-PA-RH22-S4 (119 KB)
