Balluff BOS01JK Diffuse sensors
Inexpensive and small entry-level version of our cubic diffuse sensors
Balluff BOS01JK Diffuse sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Series | 5K |
| Dimension | 10.8 x 43.5 x 19.5 mm |
| Interface | PNP NO/NC |
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Diffuse sensor, Triangulation |
| Special optical feature | Background suppression |
| Beam characteristic | Focus, typical at 260 mm |
| Light type | Laser Red light |
| Light spot size | 0.2 x 0.3 mm at focal point |
| Range | 20...300 mm |
| Connection | Connector, M8x1-Male, 4-pin |
| Housing material | PCPBT |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | cULus CE WEEE |
| UKCA | |
| Trademark | Global |
