Balluff BOS01FN Retroreflective sensors

Cubic retro-reflective sensors with different light types for washdown

Balluff BOS01FN Retroreflective sensors — datasheet, specifications, part number lookup & authentic sourcing

Get a Quote / Inquire

Specifications

Special characteristics	Washdown
Series	23K
Dimension	23 x 51 x 52.4 mm
Interface	PNP Normally open (NO)PNP Normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Retroreflective sensor
Beam characteristic	Divergent
Light type	LED Red light
Light spot size	300 x 300 mm at 12 m
Range	0...14 m
Connection	Connector, M12x1-Male, 4-pin
Housing material	PCABS
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	E c o l a b CE cULus WEEE
