Balluff BOS01FL Diffuse sensors

Cubic diffuse sensors with different light types for washdown

Balluff BOS01FL Diffuse sensors — datasheet, specifications, part number lookup & authentic sourcing

Get a Quote / Inquire

Specifications

Special characteristics	Washdown
Series	23K
Dimension	23 x 51 x 52.4 mm
Interface	PNP Normally open (NO)PNP Normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Diffuse sensor, Triangulation
Special optical feature	Background suppression
Beam characteristic	Focus, typical at 500 mm
Light type	LED Red light
Light spot size	15 x 15 mm at focal point
Range	3...800 mm
Connection	Connector, M12x1-Male, 4-pin
Housing material	PCABS
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	CE E c o l a b cULus WEEE
