Balluff

Balluff BOS01CR Retroreflective sensors

Cubic retro-reflective photoelectric sensors with different types of light up to 18 m range

Balluff BOS01CR Retroreflective sensors — datasheet, specifications, part number lookup & authentic sourcing

Get a Quote / Inquire

Specifications

Series	50K
Dimension	28.5 x 80.5 x 62 mm
Interface	PNP Normally open (NO)PNP Normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Retroreflective sensor
Beam characteristic	Divergent
Light type	LED Red light
Light spot size	200 x 200 mm at 10 m
Range	0...18 m
Connection	Connector, M12x1-Male, 4-pin
Housing material	PCABS
Material sensing surface	Glass
Operating voltage Ub	10...30 VDC
Approval/Conformity	CE cULus WEEE UKCA
