Balluff

Balluff BOS008L Retroreflective sensors

Cubic Retroreflective Photoelectric Sensors with Different Light Types up to 25 m Range

Balluff BOS008L Retroreflective sensors — datasheet, specifications, part number lookup & authentic sourcing

Get a Quote / Inquire

Specifications

Series	26K
Dimension	17 x 50 x 50 mm
Interface	PNP Normally open (NO)PNP Normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Retroreflective sensor
Special optical feature	Coaxial optics
Beam characteristic	Collimated
Light type	Laser Red light
Light spot size	Ø 20 mm at 20 m
Range	0...25 m
Connection	Connector, M12x1-Male, 4-pin
Housing material	ABS
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	cULus CE WEEE
