Balluff BOS0089 Diffuse sensors
Cubic diffuse sensors with different light types up to 60 cm range
Balluff BOS0089 Diffuse sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Series | 26K |
| Dimension | 17 x 50 x 50 mm |
| Interface | PNP Normally open (NO)PNP Normally closed (NC) |
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Diffuse sensor, Triangulation |
| Special optical feature | Background suppression |
| Light type | LED Red light |
| Light spot size | Ø 8 mm at 200 mm |
| Range | 30...300 mm |
| Connection | Connector, M12x1-Male, 4-pin |
| Housing material | ABS |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | cULus CE UKCA WEEE |
Downloads
- BOS 26K-PA-1HC-S4-C (112 KB)
