Balluff
Balluff BES05N8 Inductive Proximity Sensors
Square version with 12 mm height for temperature-resistant applications
Balluff BES05N8 Inductive Proximity Sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Dimension | 12 x 12 x 59 mm |
| Style Housing | 12x12 |
| Installation | for flush mounting |
| Range | 4 mm |
| Switching output | PNP Normally open (NO) |
| Switching frequency | 500 Hz |
| Housing material | Stainless steel |
| Material sensing surface | LCP |
| Connection | Cable, 5.0 m, Silicone |
| Operating voltage Ub | 10...30 VDC |
| Ambient temperature | -25...130 °C |
| IP rating | IP65 |
| Approval/Conformity | CE WEEE UKCA |
Downloads
- BES Q12EC-PSD40B-ES05 (78 KB)
