Balluff BES02Z3 Inductive Proximity Sensors
Cylindrical version with all-metal housing
Balluff BES02Z3 Inductive Proximity Sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Dimension | Ø 12 x 65 mm |
| Style Housing | M12x1 |
| Installation | for flush mounting |
| Range | 2 mm |
| Switching output | PNP Normally open (NO) |
| Switching frequency | 100 Hz |
| Housing material | Stainless steel |
| Material sensing surface | Stainless steel |
| Connection | Connector, M12x1-Male, 4-pin |
| Operating voltage Ub | 10...30 VDC |
| Ambient temperature | -25...70 °C |
| IP rating | IP67 |
| Approval/Conformity | CE |
| WEEE | |
| Additional features | Selective ferrous |
Downloads
- BES M12EG1-PSC20S-S04G-S (89 KB)
