Balluff
Balluff BES0180 Inductive Proximity Sensors
Square compact version
Balluff BES0180 Inductive Proximity Sensors — datasheet, specifications, part number lookup & authentic sourcing
Get a Quote / Inquire
Specifications
| Dimension | 59 x 8 x 8 mm |
| Style Housing | 8x8 |
| Installation | for flush mounting |
| Range | 1.5 mm |
| Switching output | PNP Normally open (NO) |
| Switching frequency | 5000 Hz |
| Housing material | Zinc, Die casting |
| Material sensing surface | PBT |
| Connection | Connector, M8x1-Male, 3-pin |
| Operating voltage Ub | 10...30 VDC |
| Ambient temperature | -25...70 °C |
| IP rating | IP67 |
| Approval/Conformity | CE UKCA cULus WEEE |
Downloads
- BES 516-300-S166-S49 (90 KB)
